Industrial Desk

Please check out the video link HERE to help with putting the desktop together.

Please see the generic Industrial Desk Assembly instructions. Custom desks will vary slightly but the overall process will be very similar.

What you will need

Two people capable of lifting the wooden frame and to hold the legs during assembly.

Warnings

  • Assemble the legs first using the Allen key taped to the packaging(see page 2 for a pictorial description).

  • This furniture has been made from previous industrial material.

  • While every effort has been made to make the furniture safe by sanding and cleaning, please ensure you handle the furniture with care as hazards may still exist.

  • Keep away from children when building and dismantling.

  • We advise using work gloves to reduce the possibility of splinters or cuts.

  • Please see the image below for all bolts and components to join the two desktops together.

Step 1: Connect the legs to the frame

Push part D into the clamps attached to parts B and C( as shown in image 1 to the left) until the tube is flush against the back of the clamps. Once flush use the Allen key to join the frame and the legs together. The clamps bolt is situated underneath parts B and C. Hand tighten the bolts until the frame is stable.

Step 2: Join the tabletop and place on top of the frame

The frame should now be built. Now you need to join the two tabletop pieces together using the bolts provided. Please see the video link below to help with this section.

Video link

To join the tabletop together start by placing it face down on the floor. You may want to leave the bubble wrap on the tabletop face for this part or place it on a smooth carpet to avoid damaging the tabletop surface. There are holes on both sides of the desktop underside that will align using the wooden biscuits provided. Please insert the biscuits into one of the desktops holes to help with alignment.

Once the tabletop is aligned, place the worktop bolts provided into these gaps and tighten the bolts using the spanner provided. Please tighten all three bolts simultaneously. Then use the screws to screw the wooden battens underneath the desk so that they line up with the predrilled holes on the other half of the desk.

Finally, once the frame is built place the tabletop on top of the legs and secure in place using the Allen key.

Once complete place the tabletop (part A) onto the metal frame lining up the legs with the fittings attached underneath of the tabletop.

Step 3: Attach the tabletop to the legs using the Allen key

With the legs lined up with the fittings, please tighten the fittings to the legs using the Allen key. Your table is now complete as shown in image 4 below.
industrial desk

We source our Allen keys sustainably from The Metal Store.

For a different selection on legs please click HERE or get in touch.
